• 235KhZ
• Weight: 3.9 kg (8.7 lb)
• Acoustic Window: Urethane
• Hull Deadrise: Up to 28° with fairing
• Hole Diameter: 51 mm (2?)
• Data Update Rate: 1 per second
• Minimum Depth Range: 0.5 m (1.6?)
• Maximum Depth Range: Up to 180 m (590?)
• Pressure Rating: 3 m (10?)
• Pulse Rate: 20,000 p/nm (5.6 Hz per knot)
• Supply Voltage: 9 VDC to 16 VDC
• Supply Current: 200 mA
• Standard Cable Length: 6 m (20?)
• Temperature Sensor Accuracy: 0.5°C ( 1.8°F)
• Temperature Sensor Range: -10°C to 40°C (14°F to 104°F)
• NMEA 2000 Load Equivalency Number (LEN): 4
